EV OBD with WiFi Hotspot
EV – D213
EV – D213 is an intelligent on-board diagnostic device compatible with passenger and commercial vehicles, it features plug-and-play technology, could read diagnostic info from vehicle ECU and capture location data, then send them to back-end server for real-time remote diagnostic and tracking purpose. EV – D213 can also act as an in-Vehicle Wi-Fi hotspot, up to 8 Wi-Fi enabled devices can be connected to share high speed 4G LTE network.
| Mechanical | Size | 63mm (L) x 50mm (W) x 26mm (H) |
| Weight | 50 | |
| Interface | OBD interface: 16 pin standard OBD II | |
| Configuration interface: Micro-USB | ||
| SIM card interface: Micro SIM, Push-Push Type | ||
| Data transmission | Packet data (GPRS/HSPA/LTE) and SMS | |
| Positioning method | GPS | |
| Storage | 8MB FLASH, up to 96,000 GPS data storage | |
| OBD protocol | ||
| ISO 9141-2 | ||
| ISO 14230-4 | ||
| ISO 15765-4 | ||
| SAE J1939 | ||
| SAE J1587/J1708 | ||
| Power | Working Voltage | 9-36VDC |
| Working Current | Max.: <[email protected]/27.6VDC | |
| Average: <[email protected]/27.6VDC | ||
| Sleep mode: <10mA@12/24VDC | ||
| Backup battery | 3.7V/160mAH | |
| GPS | Channels: 66 | |
| Sensitivity: -163dBm | ||
| Accuracy: 5m CEP | ||
| Time to first fix: | ||
| Cold start: <35s (typ.) | ||
| Hot start: <1s (typ.) | ||
| Wi-Fi | Frequency : | |
| 2.4-2.4835GHz | ||
| WLAN Standard: 802.11b/g/n | ||
| Transmission Data: [email protected] | ||
| [email protected] | ||
| [email protected] | ||
| Model name with “-L” version without | ||
| Wi-Fi function | ||
| Cellular | Frequency : | |
| FDD LTE | ||
| B1/B3/B8 | ||
| TDD LTE | ||
| B38/B39/B40/B41 | ||
| TD-SCDMA | ||
| B34/B39 | ||
| WCDMA/HSPA+ | ||
| B1/B8 | ||
| CDMA2000 1x/EVDO: BC0 | ||
| GSM/GPRS | ||
| 900/1800MHz | ||
| Frequency (IDD-213LE, Europe): | ||
| FDD LTE | ||
| B1/B3/B5/B7/B8/B20 | ||
| TDD LTE | ||
| B38/B40/B41 | ||
| WCDMA/HSPA+ | ||
| B1/B5/B8 | ||
| GSM/GPRS | ||
| 900/1800MHz | ||
| Frequency (IDD-213LA, US): | ||
| FDD LTE B2/B4/B12 WCDMA/HSPA+ B2/B4/B5 | ||
| Frequency(IDD-213LU, AU): | ||
| FDD LTE B1/B2/B3/B4/B5/B7/B8/B28 | ||
| TDD LTE B40 | ||
| WCDMA | ||
| B1/B2/B5/B8 | ||
| GSM/GPRS | ||
| 850/900/1800/1900MHz | ||
| Data: | ||
| LTE-FDD Max 150Mbps (DL) Max 50Mbps (UL) | ||
| LTE-TDD Max 130Mbps (DL)Max35Mbps (UL) | ||
| HSPA+ Max 42Mbps (DL) Max 5.76Mbps (UL) | ||
| Network protocol: Embedded TCP/IP stack | ||
| 6-axis IMU | Driving behavior detection | |
| LED Indication | GPS/Cellular/OBD indication | |
| Antenna | Cellular | Internal |
| GPS | Internal | |
| WIFI | Internal | |
| Accessories | ||
| OBD II extension cable | ||
| 9-Pin deutsch wiring harness | ||
| 6-Pin deutsch wiring harness | ||
| Power cable | ||
| Environment | Working Temperature | -30℃ ~ +70℃ |
| Storage Temperature | -40℃ ~ +85℃ | |
| Humidity | 5%～95%（no fog） |
- Fleet management
- Vehicle tracking
- Car rental
- Car 4S stores
- Car insurance
